Description
| Feature | Details |
|---|---|
| Transducer Frequency | CHIRP Mid-band (80–160 kHz)
ClearVü/SideVü CHIRP: 260 kHz (245–275 kHz) & 455 kHz (445–465 kHz) |
| Power Output | CHIRP Traditional: 600 W
ClearVü/SideVü: 500 W |
| Beamwidth | Traditional: 24°–13°
ClearVü/SideVü: • 2.0° × 51° @ 260 kHz • 1.4° × 29° @ 455 kHz |
| Maximum Depth | Traditional: 1,800 ft (548 m)
ClearVü: 1,000 ft (305 m) SideVü: 750 ft (229 m) |
| Cable Length | 30 ft (9.1 m) |
| Measured Parameters | Depth and Temperature |
| Connector Type | 12-pin |
| Supported Mounting Angles | 0°–70° transom or deadrise |
