Description
📦 General
- Dimension: 11.1″ x 6.5″ x 2.4″ (28.2 x 16.5 x 6.0 cm)
- Weight: 2.4 lbs (1.1 kg)
- Water rating: IPX7
- Display Type: WVGA Colour
- Display Size: 4.4″ x 7.8″ (11.2 x 19.8 cm); 9.0″ diag (22.8 cm)
- Display Resolution: 800 x 480 pixels
- Mounting Options: Flush, Tilt/Swivel
- Input: Keyed
🧭 Maps & Memory
- Waypoints / Favourites: 5000
- Track Points: 50,000
- Tracks: 50
- Navigation Routes: 100
📡 Sensors
- GPS: Yes
- Built-in Receiver: Yes
- WAAS Support: Yes
- Optional Maps: Garmin Quickdraw Contours
⚡ Electrical
- Power Input: 12 to 20 Vdc
- Typical Current Draw: 0.75 A
- Max Current Draw: 1.5 A
- Power Consumption: 9.0 W
🔊 Sonar Features
- Displays Sonar: Yes
- Traditional Sonar: Built-in (Dual Frequency/Beam)
- ClearVü: Yes
- SideVü: Yes
- Frequency: 50/77/200 kHz (CHIRP Mid & High), 260/455/800 kHz
- Transmit Power: 500 W (RMS)
- Bottom Lock: Yes
- Water Temp Log: Yes
🔌 Connections
- 4-pin Transducer Ports: 2
- Garmin Wi-Fi Network: Yes (Local Connection)
🐟 Fishfinder Features
- Split-Screen Zoom: Yes
- Fish Symbol ID: Yes
- AutoGain Technology: Yes
- Adjustable Depth Line: Yes
- A-scope: Yes
- Water Temp Sensor: Included
- Depth Range Shading: Yes
➕ Additional
- One 4-pin Transducer Port
- One 4-pin SideVü Transducer Port
- Wireless Connectivity: Yes
- Quickdraw Contours
- Integrated GPS
- Mark Waypoints
- Course Over Ground (COG)
- Current Draw @ 12V: 0.75 A
