Description
Unit dimensions, HxWxD: 9.8 x 19.7 x 14.9 cm
Weight: Radio without microphone 1.2 kg; Microphone 0.25 kg
Water rating: IPX7
Temperature range: Operating from -15°C to 70°C; Storage from -20°C to 70°C
Compass-safe distance: 75 cm
NMEA 2000: Yes
NMEA 0183: Yes
Digital selective calling: Class D
Frequency Bands: All international marine channels
Operating voltage: 12.0 Vdc
Current draw: Standby 350 mA; Receive 600 mA; Transmit from 2.0 A to 6.0 A (from 1 W to 25 W)
Frequency range: 156.050 MHz to 163.275 MHz (including WX channels)
Hailer output power: 20 W at 4 Ω
Hailer horn impedance: 4 Ω
External speaker impedance: 4 Ω
Antenna connector: S0-239 (50 Ω)
Maximum antenna gain: 9 dBi
