Description
| Feature | Details |
|---|---|
| Transducer Frequency | Traditional High Wide CHIRP (150–240 kHz)
ClearVü/SideVü: • 455 kHz (425–485 kHz) • 800 kHz (790–850 kHz) • 1000 kHz (940–1100 kHz) |
| Power Output | Traditional: 350 W
ClearVü/SideVü: 500 W |
| Beamwidth | Traditional CHIRP: 24°–16°
ClearVü: • 0.52° × 52° @ 1000 kHz • 0.64° × 35° @ 800 kHz • 1.1° × 52° @ 455 kHz SideVü: • 0.52° × 52° @ 1000 kHz • 0.64° × 35° @ 800 kHz • 1.1° × 52° @ 455 kHz |
| Maximum Depth | Traditional: 244 m (freshwater)
ClearVü: 122 m SideVü: 152 m |
| Cable Length | 7.62 m |
| Measured Parameters | Depth and Temperature |
| Connector Type | 12-pin |
| Supported Mounting Angles | 0°–70° transom |
| Dimensions (without mount) | 218.5 mm × 51.8 mm × 27.7 mm |
