Description
| Feature | Details |
|---|---|
| Transducer Frequency | Traditional CHIRP: High Wide (150–240 kHz)
Ultra High-Definition ClearVü: 800 kHz (CHIRP 760–880 kHz) Ultra High-Definition SideVü: 1200 kHz (CHIRP 1080–1230 kHz) SideVü: 455 kHz (CHIRP 425–485 kHz) |
| Power Output | Traditional CHIRP: 350 W
UHD ClearVü: 350 W UHD SideVü: 350 W SideVü: 350 W |
| Beamwidth | Traditional CHIRP: Adjustable 16°–24° (1° steps)
UHD ClearVü: 0.94° × 60° UHD SideVü: 0.64° × 52° SideVü: 1.62° × 50° |
| Maximum Depth | Traditional CHIRP: 243 m (800 ft)
UHD ClearVü: 60 m (200 ft) UHD SideVü: 38 m (125 ft) per side (max depth 9 m/30 ft) SideVü: 152.4 m (500 ft) per side |
| Depth/Speed/Temperature | Measures Depth and Temperature |
| Number of Pins | 12-pin (orange connector) |
| Cable Length | 6 m (20 ft) |
| Supported Mounting Angles | 0°–70° transom |
